authentik
Serverless Observability Serverless Security Stack
| Version | 1.6.0 (View all) |
| Subscription level What's this? | Basic |
| Level of support What's this? | Elastic |
| Ingestion method(s) | API |
authentik is an IdP (Identity Provider) and SSO (single sign on) that is built with security at the forefront of every piece of code, every feature, with an emphasis on flexibility and versatility.
The authentik integration collects event, group, and user logs using REST API.
The authentik integration collects three types of logs:
Elastic Agent must be installed. For more details, check the Elastic Agent installation instructions.
- Log in to your authentik instance to obtain your API Token.
- Open the Admin interface and navigate to Directory > Tokens and App passwords.
- Create the API Token, save and copy it somewhere.
- In Kibana navigate to Management > Integrations.
- In the search bar, type Authentik.
- Select the Authentik integration and add it.
- Add all the required integration configuration parameters, including API Token, Interval and Page Size to enable data collection.
- Save the integration.
This is the event dataset.
Example
{ "@timestamp": "2024-08-05T15:41:18.411Z", "agent": { "ephemeral_id": "1306b1a8-e483-4b73-8a9f-0c9693b0850a", "id": "c92576df-b24c-47aa-bfeb-01fed074d411", "name": "elastic-agent-33100", "type": "filebeat", "version": "8.16.0" }, "authentik": { "event": { "action": "user_write", "app": "authentik.events.signals", "brand": { "app": "authentik_brands", "model_name": "brand", "name": "Default brand", "pk": "fcba828076b94dedb2d5a6b4c5556fa1" }, "client_ip": "67.43.156.0", "context": { "created": false, "email": "root@localhost", "http_request": { "method": "GET", "path": "/api/v3/flows/executor/default-user-settings-flow/" }, "name": "authentik Default Admin", "username": "akadmin" }, "created": "2024-08-05T15:41:18.411Z", "expires": "2024-08-06T15:41:18.410Z", "pk": "d012e8af-cb94-4fa2-9e92-961e4eebc060", "user": { "email": "root@localhost", "pk": "1", "username": "akadmin" } } }, "data_stream": { "dataset": "authentik.event", "namespace": "99344", "type": "logs" }, "ecs": { "version": "8.11.0" }, "elastic_agent": { "id": "c92576df-b24c-47aa-bfeb-01fed074d411", "snapshot": false, "version": "8.16.0" }, "event": { "action": "user-write", "agent_id_status": "verified", "category": [ "iam" ], "created": "2024-08-05T15:41:18.411Z", "dataset": "authentik.event", "id": "d012e8af-cb94-4fa2-9e92-961e4eebc060", "ingested": "2025-07-09T09:38:33Z", "kind": "event", "original": "{\"action\":\"user_write\",\"app\":\"authentik.events.signals\",\"brand\":{\"app\":\"authentik_brands\",\"model_name\":\"brand\",\"name\":\"Default brand\",\"pk\":\"fcba828076b94dedb2d5a6b4c5556fa1\"},\"client_ip\":\"67.43.156.0\",\"context\":{\"attributes\":{\"settings\":{\"locale\":\"\"}},\"created\":false,\"email\":\"root@localhost\",\"http_request\":{\"args\":{\"query\":\"\"},\"method\":\"GET\",\"path\":\"/api/v3/flows/executor/default-user-settings-flow/\"},\"name\":\"authentik Default Admin\",\"username\":\"akadmin\"},\"created\":\"2024-08-05T15:41:18.411017Z\",\"expires\":\"2024-08-06T15:41:18.410276Z\",\"pk\":\"d012e8af-cb94-4fa2-9e92-961e4eebc060\",\"user\":{\"email\":\"root@localhost\",\"pk\":1,\"username\":\"akadmin\"}}", "type": [ "change" ] }, "http": { "request": { "method": "GET" } }, "input": { "type": "cel" }, "observer": { "product": "authentik", "vendor": "authentik" }, "related": { "ip": [ "67.43.156.0" ], "user": [ "root@localhost", "1", "akadmin" ] }, "source": { "geo": { "continent_name": "Asia", "country_iso_code": "BT", "country_name": "Bhutan", "location": { "lat": 27.5, "lon": 90.5 } }, "ip": "67.43.156.0" }, "tags": [ "preserve_original_event", "preserve_duplicate_custom_fields", "forwarded", "authentik-event" ], "url": { "path": "/api/v3/flows/executor/default-user-settings-flow/" }, "user": { "domain": "localhost", "email": "root@localhost", "id": "1", "name": "akadmin" } } Exported fields
| Field | Description | Type |
|---|---|---|
| @timestamp | Event timestamp. | date |
| authentik.event.action | keyword | |
| authentik.event.app | keyword | |
| authentik.event.brand.app | keyword | |
| authentik.event.brand.model_name | keyword | |
| authentik.event.brand.name | keyword | |
| authentik.event.brand.pk | keyword | |
| authentik.event.client_ip | ip | |
| authentik.event.context.auth_method | keyword | |
| authentik.event.context.authorized_application.app | keyword | |
| authentik.event.context.authorized_application.model_name | keyword | |
| authentik.event.context.authorized_application.name | keyword | |
| authentik.event.context.authorized_application.pk | keyword | |
| authentik.event.context.binding.app | keyword | |
| authentik.event.context.binding.model_name | keyword | |
| authentik.event.context.binding.name | keyword | |
| authentik.event.context.binding.pk | keyword | |
| authentik.event.context.created | boolean | |
| authentik.event.context.diff | flattened | |
| authentik.event.context.email | keyword | |
| authentik.event.context.expression | keyword | |
| authentik.event.context.flow | keyword | |
| authentik.event.context.http_request.args.client_id | keyword | |
| authentik.event.context.http_request.args.format_result | keyword | |
| authentik.event.context.http_request.args.include_groups | keyword | |
| authentik.event.context.http_request.args.next | keyword | |
| authentik.event.context.http_request.args.page_size | keyword | |
| authentik.event.context.http_request.args.query | keyword | |
| authentik.event.context.http_request.args.redirect_uri | keyword | |
| authentik.event.context.http_request.args.response_type | keyword | |
| authentik.event.context.http_request.args.scope | keyword | |
| authentik.event.context.http_request.args.state | keyword | |
| authentik.event.context.http_request.method | keyword | |
| authentik.event.context.http_request.path | keyword | |
| authentik.event.context.http_request.user_agent | keyword | |
| authentik.event.context.message | keyword | |
| authentik.event.context.model.app | keyword | |
| authentik.event.context.model.model_name | keyword | |
| authentik.event.context.model.name | keyword | |
| authentik.event.context.model.pk | keyword | |
| authentik.event.context.name | keyword | |
| authentik.event.context.new_version | keyword | |
| authentik.event.context.password | keyword | |
| authentik.event.context.policy_uuid | keyword | |
| authentik.event.context.request.context.event.app | keyword | |
| authentik.event.context.request.context.event.model_name | keyword | |
| authentik.event.context.request.context.event.name | keyword | |
| authentik.event.context.request.context.event.pk | keyword | |
| authentik.event.context.request.obj.app | keyword | |
| authentik.event.context.request.obj.model_name | keyword | |
| authentik.event.context.request.obj.name | keyword | |
| authentik.event.context.request.obj.pk | keyword | |
| authentik.event.context.request.user.email | keyword | |
| authentik.event.context.request.user.pk | keyword | |
| authentik.event.context.request.user.username | keyword | |
| authentik.event.context.result.passing | boolean | |
| authentik.event.context.scopes | keyword | |
| authentik.event.context.secret.app | keyword | |
| authentik.event.context.secret.model_name | keyword | |
| authentik.event.context.secret.name | keyword | |
| authentik.event.context.secret.pk | keyword | |
| authentik.event.context.stage.app | keyword | |
| authentik.event.context.stage.model_name | keyword | |
| authentik.event.context.stage.name | keyword | |
| authentik.event.context.stage.pk | keyword | |
| authentik.event.context.token.app | keyword | |
| authentik.event.context.token.model_name | keyword | |
| authentik.event.context.token.name | keyword | |
| authentik.event.context.token.pk | keyword | |
| authentik.event.context.username | keyword | |
| authentik.event.created | date | |
| authentik.event.expires | date | |
| authentik.event.pk | keyword | |
| authentik.event.user.email | keyword | |
| authentik.event.user.is_anonymous | boolean | |
| authentik.event.user.on_behalf_of.email | keyword | |
| authentik.event.user.on_behalf_of.pk | keyword | |
| authentik.event.user.on_behalf_of.username | keyword | |
| authentik.event.user.pk | keyword | |
| authentik.event.user.username | keyword | |
| data_stream.dataset | Data stream dataset. | constant_keyword |
| data_stream.namespace | Data stream namespace. | constant_keyword |
| data_stream.type | Data stream type. | constant_keyword |
| event.dataset | Event dataset. | constant_keyword |
| event.module | Event module. | constant_keyword |
| input.type | Type of filebeat input. | keyword |
| log.offset | Log offset. | long |
This is the group dataset.
Example
{ "@timestamp": "2025-07-08T10:42:33.381Z", "agent": { "ephemeral_id": "4b426494-b60b-4a12-b26d-371de0e70570", "id": "7e087d11-bca0-40d1-9322-dbe06d6900e6", "name": "elastic-agent-25925", "type": "filebeat", "version": "8.16.0" }, "authentik": { "group": { "attributes": { "ldap_uniq": "S-1-5-21-1234567890-1234567890-1234567890-1234" }, "is_superuser": false, "name": "AllUsers", "num_pk": 55003, "pk": "29613be9-2db3-4488-9338-60ec7762f60d", "users": [ "12", "14", "15", "7", "9", "13", "8", "16", "11", "6", "4" ] } }, "data_stream": { "dataset": "authentik.group", "namespace": "58753", "type": "logs" }, "ecs": { "version": "8.11.0" }, "elastic_agent": { "id": "7e087d11-bca0-40d1-9322-dbe06d6900e6", "snapshot": false, "version": "8.16.0" }, "event": { "agent_id_status": "verified", "category": [ "iam" ], "dataset": "authentik.group", "ingested": "2025-07-08T10:42:36Z", "kind": "asset", "module": "authentik", "original": "{\"attributes\":{\"ldap_uniq\":\"S-1-5-21-1234567890-1234567890-1234567890-1234\"},\"is_superuser\":false,\"name\":\"AllUsers\",\"num_pk\":55003,\"parent\":null,\"parent_name\":null,\"pk\":\"29613be9-2db3-4488-9338-60ec7762f60d\",\"roles\":[],\"roles_obj\":[],\"users\":[12,14,15,7,9,13,8,16,11,6,4],\"users_obj\":null}", "type": [ "group", "info" ] }, "group": { "id": "29613be9-2db3-4488-9338-60ec7762f60d", "name": "AllUsers" }, "input": { "type": "cel" }, "observer": { "product": "authentik", "vendor": "authentik" }, "related": { "user": [ "12", "14", "15", "7", "9", "13", "8", "16", "11", "6", "4" ] }, "tags": [ "preserve_original_event", "preserve_duplicate_custom_fields", "forwarded", "authentik-group" ], "user": { "id": [ "12", "14", "15", "7", "9", "13", "8", "16", "11", "6", "4" ] } } Exported fields
| Field | Description | Type |
|---|---|---|
| @timestamp | Event timestamp. | date |
| authentik.group.attributes.ldap_uniq | keyword | |
| authentik.group.attributes.notes | keyword | |
| authentik.group.is_superuser | Users added to this group will be superusers. | boolean |
| authentik.group.name | keyword | |
| authentik.group.num_pk | long | |
| authentik.group.parent | keyword | |
| authentik.group.parent_name | keyword | |
| authentik.group.pk | keyword | |
| authentik.group.roles | keyword | |
| authentik.group.roles_obj.name | keyword | |
| authentik.group.roles_obj.pk | keyword | |
| authentik.group.users | keyword | |
| data_stream.dataset | Data stream dataset. | constant_keyword |
| data_stream.namespace | Data stream namespace. | constant_keyword |
| data_stream.type | Data stream type. | constant_keyword |
| event.dataset | Event dataset. | constant_keyword |
| event.module | Event module. | constant_keyword |
| input.type | Type of filebeat input. | keyword |
| log.offset | Log offset. | long |
This is the user dataset.
Example
| Field | Description | Type |
|---|---|---|
| @timestamp | Event timestamp. | date |
| authentik.user.attributes.ldap_uniq | keyword | |
| authentik.user.attributes.sn | keyword | |
| authentik.user.attributes.upn | keyword | |
| authentik.user.avatar | keyword | |
| authentik.user.email | keyword | |
| authentik.user.groups | keyword | |
| authentik.user.is_active | boolean | |
| authentik.user.is_superuser | boolean | |
| authentik.user.last_login | date | |
| authentik.user.name | keyword | |
| authentik.user.path | keyword | |
| authentik.user.pk | keyword | |
| authentik.user.type | keyword | |
| authentik.user.uid | keyword | |
| authentik.user.username | keyword | |
| authentik.user.uuid | keyword | |
| data_stream.dataset | Data stream dataset. | constant_keyword |
| data_stream.namespace | Data stream namespace. | constant_keyword |
| data_stream.type | Data stream type. | constant_keyword |
| event.dataset | Event dataset. | constant_keyword |
| event.module | Event module. | constant_keyword |
| input.type | Type of filebeat input. | keyword |
| log.offset | Log offset. | long |
This integration includes one or more Kibana dashboards that visualizes the data collected by the integration. The screenshots below illustrate how the ingested data is displayed.
Changelog
| Version | Details | Kibana version(s) |
|---|---|---|
| 1.6.0 | Enhancement (View pull request) Improve documentation to align with new guidelines. | 8.16.0 or higher 9.0.0 or higher |
| 1.5.0 | Enhancement (View pull request) Use terminate processor instead of fail processor to handle agent errors. | 8.16.0 or higher 9.0.0 or higher |
| 1.4.0 | Enhancement (View pull request) Remove redundant installation instructions. | 8.13.0 or higher 9.0.0 or higher |
| 1.3.0 | Enhancement (View pull request) Update Kibana constraint to support 9.0.0. | 8.13.0 or higher 9.0.0 or higher |
| 1.2.2 | Bug fix (View pull request) Updated SSL description in package manifest.yml to be uniform and to include links to documentation. | 8.13.0 or higher |
| 1.2.1 | Bug fix (View pull request) Defensively copy list parameters in 'Set ECS categorization fields' script. | 8.13.0 or higher |
| 1.2.0 | Enhancement (View pull request) Add "preserve_original_event" tag to documents with event.kind manually set to "pipeline_error". | 8.13.0 or higher |
| 1.1.1 | Bug fix (View pull request) Fix broken links in Security Service integrations packages. | 8.13.0 or higher |
| 1.1.0 | Enhancement (View pull request) Add "preserve_original_event" tag to documents with event.kind set to "pipeline_error". | 8.13.0 or higher |
| 1.0.0 | Enhancement (View pull request) Release package as GA. | 8.13.0 or higher |
| 0.1.0 | Enhancement (View pull request) Initial release. | — |
