(2) Introduction of C# Basics – Part I Nico Ludwig (@ersatzteilchen)

2 TOC ● (2) Introduction of C# Basics – Part I – A Tour through other .Net Programming Languages – C# Syntax Cornerstones

3 Challenge: Parse an Update Log ● Userstory: "As an administrator I want to know the latest updates on a PC, in order to get a report of that PC's state!" ● It is needed to parse the file "Software Update.log": 2009-04-06 12:43:04 +0200: Installed "GarageBand Update" (5.0.1) 2009-04-06 12:44:34 +0200: Installed "iMovie Update" (8.0.1) 2009-07-30 13:11:28 +0200: Installed "iMovie Update" (8.0.4) 2009-04-06 12:43:31 +0200: Installed "iTunes" (8.1) … ● How can we solve this problem?

4 Visual Basic 10 (VB 10) Imports System Imports System.IO Imports System.Collections.Generic Imports System.Text.RegularExpressions Module Program Sub Main() ' check arguments from console If (0 < My.Application.CommandLineArgs.Count) Then Dim latestUpdates As IDictionary(Of String, String) = New SortedDictionary(Of String, String) Dim parseRex As Regex = New Regex("[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))") ' open and check file, read a line For Each aLine As String In File.ReadAllLines(My.Application.CommandLineArgs.Item(0)) ' parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5) Dim match As Match = parseRex.Match(aLine) If (match.Success) Then ' store the parsed data Dim appName As String = match.Groups.Item("appName").ToString() Dim versionNo As String = match.Groups.Item("versionNo").ToString() If (latestUpdates.ContainsKey(appName)) Then If (0 < String.CompareOrdinal(versionNo, latestUpdates.Item(appName))) Then latestUpdates.Item(appName) = versionNo End If Else latestUpdates.Add(appName, versionNo) End If End If Next ' output the collected data to console For Each item As KeyValuePair(Of String, String) In latestUpdates Console.WriteLine("App: {0}, Latest Update: {1}", item.Key, item.Value) Next End If End Sub End Module

5 C++/CLI – Part I #include "stdafx.h" using namespace System; using namespace System::IO; using namespace System::Collections::Generic; using namespace System::Text::RegularExpressions; int main(array<String^>^ args) { // check arguments from console if (0 < args->Length) { IDictionary<String^, String^>^ latestUpdates = gcnew SortedDictionary<String^, String^>(); Regex^ parseRex = gcnew Regex("[^"]*"(?<appName>[^"]*)"s*((?<versionNo>[^(]*))"); // open and check file, read a line for each (String^ aLine in File::ReadAllLines(args[0])) { // parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5) Match^ match = parseRex->Match(aLine); if (match->Success) { // store the parsed data String^ appName = match->Groups["appName"]->ToString(); String^ versionNo = match->Groups["versionNo"]->ToString(); if (latestUpdates->ContainsKey(appName)) { if (0 < String::CompareOrdinal(versionNo, latestUpdates[appName])) { latestUpdates[appName] = versionNo; } } else

6 C++/CLI – Part II { latestUpdates->Add(appName, versionNo); } } } // output the collected data to console for each (KeyValuePair<String^, String^>^ item in latestUpdates) { Console::WriteLine("App: {0}, Latest Update: {1}", item->Key, item->Value); } } }

7 F# 3 #light open System open System.IO open System.Text.RegularExpressions if 2 >= Environment.GetCommandLineArgs().Length then let parseRex = new Regex(@"[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))") // open and check file, read the lines, parse and process the data, output the processed data to console File.ReadLines(Environment.GetCommandLineArgs().GetValue(1).ToString()) |> Seq.map(parseRex.Match) |> Seq.filter(fun theMatch -> theMatch.Success) |> Seq.sortBy(fun theMatch -> theMatch.Groups.Item("versionNo").ToString()) |> Seq.map(fun theMatch -> theMatch.Groups.Item("appName").ToString(), theMatch.Groups.Item("versionNo").ToString()) |> dict |> Seq.sortBy(fun item -> item.Key) |> Seq.iter(fun item -> printfn "App: %s, Latest Update: %s" item.Key item.Value)

8 C# 5 – Part I using System; using System.IO; using System.Collections.Generic; using System.Text.RegularExpressions; public class Program { public static void Main(string[] args) { // check arguments from console if (0 < args.Length) { IDictionary<string, string> latestUpdates = new SortedDictionary<string, string>(); Regex parseRex = new Regex(@"[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))"); // open and check file, read a line foreach (string aLine in File.ReadAllLines(args[0])) { // parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5) Match match = parseRex.Match(aLine); if (match.Success) { // store the parsed data string appName = match.Groups["appName"].ToString(); string versionNo = match.Groups["versionNo"].ToString(); if (latestUpdates.ContainsKey(appName)) { if (0 < string.CompareOrdinal(versionNo, latestUpdates[appName])) { latestUpdates[appName] = versionNo; } } else

9 C# 5 – Part II { latestUpdates.Add(appName, versionNo); } } } // output the collected data to console foreach (KeyValuePair<string, string> item in latestUpdates) { Console.WriteLine("App: {0}, Latest Update: {1}", item.Key, item.Value); } } } }

10 Common Intermediate Language (CIL, also just IL) IL_0001: ldc.i4.1 IL_0002: newarr System.String IL_0007: stloc.s 08 // CS$0$0000 IL_0009: ldloc.s 08 // CS$0$0000 IL_000B: ldc.i4.0 IL_000C: ldstr "C:UsersnludwigDesktopapplication.properties" IL_0011: stelem.ref IL_0012: ldloc.s 08 // CS$0$0000 IL_0014: stloc.0 // args IL_0015: ldc.i4.0 IL_0016: ldloc.0 // args IL_0017: ldlen IL_0018: conv.i4 IL_0019: clt IL_001B: ldc.i4.0 IL_001C: ceq IL_001E: stloc.s 09 // CS$4$0001 IL_0020: ldloc.s 09 // CS$4$0001 IL_0022: brtrue IL_0154 IL_0028: newobj System.Collections.Generic.SortedDictionary<System.String,System.String>..ctor IL_002D: stloc.1 // latestUpdates IL_002E: ldstr "[^"]*"(?<appName>[^"]*)"s*((?<versionNo>[^(]*))" IL_0033: newobj System.Text.RegularExpressions.Regex..ctor IL_0038: stloc.2 // parseRex IL_003A: ldloc.0 // args IL_003B: ldc.i4.0 IL_003C: ldelem.ref IL_003D: call System.IO.File.ReadAllLines IL_0042: stloc.s 0A // CS$6$0002 IL_0044: ldc.i4.0 IL_0045: stloc.s 0B // CS$7$0003 IL_0047: br IL_00EF IL_004C: ldloc.s 0A // CS$6$0002 IL_004E: ldloc.s 0B // CS$7$0003 IL_0050: ldelem.ref IL_0051: stloc.3 // aLine IL_0053: ldloc.2 // parseRex IL_0054: ldloc.3 // aLine IL_0055: callvirt System.Text.RegularExpressions.Regex.Match IL_005A: stloc.s 04 // match IL_005C: ldloc.s 04 // match IL_005E: callvirt System.Text.RegularExpressions.Group.get_Success IL_0063: ldc.i4.0 IL_0064: ceq IL_0066: stloc.s 09 // CS$4$0001 IL_0068: ldloc.s 09 // CS$4$0001 IL_006A: brtrue.s IL_00E8 IL_006D: ldloc.s 04 // match IL_006F: callvirt System.Text.RegularExpressions.Match.get_Groups IL_0074: ldstr "appName" IL_0079: callvirt System.Text.RegularExpressions.GroupCollection.get_Item IL_007E: callvirt System.Object.ToString IL_0083: stloc.s 05 // appName IL_0085: ldloc.s 04 // match IL_0087: callvirt System.Text.RegularExpressions.Match.get_Groups IL_008C: ldstr "versionNo" IL_0091: callvirt System.Text.RegularExpressions.GroupCollection.get_Item IL_0096: callvirt System.Object.ToString IL_009B: stloc.s 06 // versionNo IL_009D: ldloc.1 // latestUpdates IL_009E: ldloc.s 05 // appName IL_00A0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.ContainsKey IL_00A5: ldc.i4.0 IL_00A6: ceq IL_00A8: stloc.s 09 // CS$4$0001 IL_00AA: ldloc.s 09 // CS$4$0001 IL_00AC: brtrue.s IL_00DA IL_00AF: ldc.i4.0 IL_00B0: ldloc.s 06 // versionNo IL_00B2: ldloc.1 // latestUpdates IL_00B3: ldloc.s 05 // appName IL_00B5: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.get_Item IL_00BA: call System.String.CompareOrdinal IL_00BF: clt IL_00C1: ldc.i4.0 IL_00C2: ceq IL_00C4: stloc.s 09 // CS$4$0001 IL_00C6: ldloc.s 09 // CS$4$0001 IL_00C8: brtrue.s IL_00D7 IL_00CB: ldloc.1 // latestUpdates IL_00CC: ldloc.s 05 // appName IL_00CE: ldloc.s 06 // versionNo IL_00D0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.set_Item IL_00D8: br.s IL_00E7 IL_00DB: ldloc.1 // latestUpdates IL_00DC: ldloc.s 05 // appName IL_00DE: ldloc.s 06 // versionNo IL_00E0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.Add IL_00E9: ldloc.s 0B // CS$7$0003 IL_00EB: ldc.i4.1 IL_00EC: add IL_00ED: stloc.s 0B // CS$7$0003 IL_00EF: ldloc.s 0B // CS$7$0003 IL_00F1: ldloc.s 0A // CS$6$0002 IL_00F3: ldlen IL_00F4: conv.i4 IL_00F5: clt IL_00F7: stloc.s 09 // CS$4$0001 IL_00F9: ldloc.s 09 // CS$4$0001 IL_00FB: brtrue IL_004C IL_0101: ldloc.1 // latestUpdates IL_0102: callvirt System.Collections.Generic.IEnumerable<System.Collections.Generic.KeyValuePair<System.String,System.String>>.GetEnumerator IL_0107: stloc.s 0C // CS$5$0004 IL_0109: br.s IL_012F IL_010B: ldloc.s 0C // CS$5$0004 IL_010D: callvirt System.Collections.Generic.IEnumerator<System.Collections.Generic.KeyValuePair<System.String,System.String>>.get_Current IL_0112: stloc.s 07 // item IL_0115: ldstr "App: {0}, Latest Update: {1}" IL_011A: ldloca.s 07 // item IL_011C: call System.Collections.Generic.KeyValuePair<System.String,System.String>.get_Key IL_0121: ldloca.s 07 // item IL_0123: call System.Collections.Generic.KeyValuePair<System.String,System.String>.get_Value IL_0128: call System.Console.WriteLine IL_012F: ldloc.s 0C // CS$5$0004 IL_0131: callvirt System.Collections.IEnumerator.MoveNext IL_0136: stloc.s 09 // CS$4$0001 IL_0138: ldloc.s 09 // CS$4$0001 IL_013A: brtrue.s IL_010B IL_013C: leave.s IL_0152 IL_013E: ldloc.s 0C // CS$5$0004 IL_0140: ldnull IL_0141: ceq IL_0143: stloc.s 09 // CS$4$0001 IL_0145: ldloc.s 09 // CS$4$0001 IL_0147: brtrue.s IL_0151 IL_0149: ldloc.s 0C // CS$5$0004 IL_014B: callvirt System.IDisposable.Dispose IL_0151: endfinally

11 What is the C# programming language? ● C# is standardized in ECMA-334. ● C# blends features of C++, Java and other popular languages. – Without C# being based on Java, .Net would not have been a success! ● A CLS compliant language, ECMA and ISO/IEC standard. ● Major platform is Windows (compilers and CLR from MS).

12 C# Core Features ● Multiparadigm language. ● Static typing by default. ● C-style syntax with extensions. ● CTS is the first class type system. ● C# is popular and evolving. – Relatively short innovation cycles. Learned stuff gets stale early (~two years). ● C# is relatively simple to learn. – It is basically pointer free. (We could use pointers. The CTS doesn't use pointers.) – It doesn't use manual memory management, the runtime has a garbage collector.

13 Structure of a C# Console Application // Program.cs using System; namespace ConsoleApplication { public class Program { // The execution of a program always starts in the method Main(). public static void Main(string[] args) { Console.WriteLine("Hello World!"); } } }

14 Code Snippets ● Hence we'll begin using snippets as code examples, i.e. no Main() etc.! // Program.cs using System; namespace ConsoleApplication { public class Program { public static void Main(string[] args) { Console.WriteLine("Hello World!"); } } } Console.WriteLine("Hello World!"); ● In the end no fully runnable program code will be shown in upcoming lectures!

15 C# as a compiled Language ● C# reserves symbols for its grammar, these are called keywords. ● Syntax versus Semantics: int count = 2; count = 2; – Both statements do not mean the same, but the syntax is similar! – Locals need to be initialized, uninitialized fields have default values. ● Compile time errors versus run time errors: int zero = 0; int oddResult = 42/zero; – Both statements are ok for the compiler. ● But the last one throws a DivisionByZeroException at run time.

16 C# Syntax Cornerstones – Part I – Imperative Elements if (answerIsOk) { Console.WriteLine("Result: "+(3 + 4)); } ● Basic elements: expressions, statements, blocks. They can be freely formatted. – Imperative programming: Statements and blocks are executed sequentially. – The order of execution of expressions is strictly defined in C#! ● The most elementary statements are variable definitions. – Variable definitions make variables applicable in the code. – By default, variables need to be typed on definition, this is called static typing. ● Implicit and dynamic typing is also possible, but we stick to explicit static typing in this course. ● Besides definition, variables can be initialized and assigned to. – Initialization gives initial values to a variable. – Assignment sets a variable to a new value. int age = 19; age = 25; double width = 32.8;

17 C# Syntax Cornerstones – Part II – Types ● Primitive types are integrated types, whose objects can be created with literals. – Simple value integral types: int, long (etc.). – Simple value float types: float, double (etc.). – Simple value boolean type: bool. – Simple value character type: char. – Reference text type: string. (an alias C# keyword for the .Net type System.String) – We can create compile time constants (const) of primitive type. ● There exist value types (e.g. int) and reference types (e.g. string). – Variables of reference type are often simply called references. ● Explicit type conversion: // Conversion with cast: int i = (int)2.78; – Explicit conversions are done with explicit casts or the as operator. – Explicit conversions can be done safely with checked expressions and contexts. – The type System.Convert (various types) and the methods ToString()/Parse() (string). // Conversion with as: string text = choice as string;

18 C# Syntax Cornerstones – Part III – Identifiers and Comments • C# uses case sensitive identifiers, we have to obey common conventions. – aString is not the same identifier as aStRiNg! – We've to use a common notation (e.g. camelCase or PascalCase) as convention! – Language specific characters can be used (e.g. umlauts) as well as the underscore. – C# keywords mustn't be used as identifiers. • Comments can be applied everywhere in code. We should exploit comments! /* commented */ /** commented */ // commented /// commented (triple slash) • The usage and definition of methods will be discussed later. – Methods are .Net's pendant of functions/member functions in other languages. • In the next slides we're going to understand the most important operators in C#.

19 Operator Notations – Arity ● Binary operators // Addition as binary operator: int sum = 2 + 3; ● Unary operators // Increment as unary operator: int i = 1; ++i; // Increments i (the result is 2). ● Ternary operator // The conditional operator is the only ternary operator: int i = 2; int j = 3; string answer = (i < j) ? "i less than j" : "i not less than j";

20 Operator Notations – Placement ● Prefix operators // Negation as prefix operator: bool succeeded = !failed; ● Postfix operators // Increment as postfix operator: int result = item++; ● Infix operators // Addition as infix operator: int sum = 2 + 3;

21 Mathematical Operators ● Binary +, - and *, / are known form elementary mathematics. – Attention: Integer division yields an integer result! – The result of the division by 0 results in a run time error. ● A DivisionByZeroException will be thrown. ● Unary – and + as sign-operators. ● Somewhat special: ++/-- and % ● Math.Log(), Math.Pow() and other operations in the class Math. ● Bit operations work with integers as arguments and result in integers. – Operators: ^, |, &, ~, <<, >>

22 Other Operators and Operator Overloading ● Assignment and combined assignment. – Operators: =, +=, *=, /= etc. – Operators: &=, |=, ^=, <<=, >>= ● Concatenation of strings with the operators + and +=. – But: strings are still immutable! ● Important extra operators: – Operators: [], (), ?:, ??, new, is, as, typeof – Operators: ., :: – Operators: *, ->, sizeof – Operators: => int i = 12; i = i + 2; // (i = 14) Add and assign. i += 2; // (i = 16) Add-combined assignment. ● C# permits to redefine (overload) operators for user defined types UDT.

23 Logical Operators ● Used to compare values and combine boolean results. – Comparison: ==, !=, <, >, <=, >= – Combination: &&, ||, ! – Logical operators return boolean results, not integral results. ● && (logical and) and || (logical or) support short circuit evaluation. // The mathematic boolean expression a = b and c = b: // Ok if (a == b && c == b) { /* pass */ } // Wrong! if (a && b == c) { /* pass */ } ● Logical operators are applied in conditional expressions for control structures (branches and loops).

24 Precedence, Associativity and Order of Execution ● Precedence and precedence groups. – Some operators have the same precedence and make up a precedence group. – As operator priority in maths, precedence is controllable with parentheses. ● Associativity defines evaluation among expressions of the same precedence. – Associativity is defined as a "direction". – Associativity is controllable with parentheses as well. ● The order of execution within expressions is strictly defined in C#. – The order is from left to right and from inner to outer. int i = 0; Console.WriteLine("{0} {1}", i++, i); // >0 1 → Always this result … // Never 0 0!
