//官网下载kafka和zookeeper，并解压... //kafka启动前需要启动zk $ bin/zookeeper-server-start.sh config/zookeeper.properties //启动kafka，默认本机9092 $ bin/kafka-server-start.sh config/server.properties //使用kafka自带脚本创建一个 名字叫quickstart-events的 topic $ bin/kafka-topics.sh --create --topic quickstart-events --bootstrap-server localhost:9092

 <dependency> <groupId>org.apache.kafka</groupId> <artifactId>kafka-clients</artifactId> <version>2.2.2</version> </dependency> <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-sql_2.12</artifactId> <version>3.1.2</version> </dependency> <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-sql-kafka-0-10_2.12</artifactId> <version>3.1.2</version> </dependency>

public static void main(String[] args) throws Exception { SparkConf config = new SparkConf().setAppName("JavaStructuredKafkaWordCount").setMaster("local[1]"); SparkContext sparkContext = new SparkContext(config); SparkSession spark = new SparkSession(sparkContext); // Create DataSet representing the stream of input lines from kafka Dataset<String> lines = spark .readStream() .format("kafka") .option("kafka.bootstrap.servers", "127.0.0.1:9092") .option("subscribe", "quickstart-events") .load() .selectExpr("CAST(value AS STRING)") .as(Encoders.STRING()); // Generate running word count Dataset<org.apache.spark.sql.Row> wordCounts = lines.flatMap( (FlatMapFunction<String, String>) x -> Arrays.asList(x.split(" ")).iterator(), Encoders.STRING()).groupBy("value").count(); // Start running the query that prints the running counts to the console StreamingQuery query = wordCounts.writeStream() .outputMode("complete") .format("console") .start(); query.awaitTermination(); }

 //启动一个生产者,这样就可以在shell中给topic发消息 $ bin/kafka-console-producer.sh --topic quickstart-events --bootstrap-server localhost:9092 //输入后回车 > hello owen > hello lemon > byebye

 ------------------------------------------- Batch: 1 ------------------------------------------- +------+-----+ | value|count| +------+-----+ | hello| 2| | owen| 1| |byebye| 1| | lemon| 1| +------+-----+

javax.sql.DataSource

Data source interfaces in Spark 2.3.0 主要有以下的接口 - StreamSourceProvider - Source - StreamSinkProvider - Sink

Data Source interfaces in Spark 3.0.0 主要有以下的接口 - TableProvider - Table - ScanBuilder - Scan - MicroBatchStream - InputPartition - PartitionReaderFactory - PartitionReader

private[kafka010] class KafkaSourceProvider extends DataSourceRegister //V1 接口 with StreamSourceProvider // V2 接口 with StreamSinkProvider // V2 接口 with RelationProvider // V1 接口 with CreatableRelationProvider // V1 接口 with SimpleTableProvider //Spark 3.x 数据源接口 with Logging {

private[kafka010] class KafkaSourceProvider extends SimpleTableProvider // 1.Spark 3.x 数据源接口 with Logging { //2.getTable()方法，传入用户参数options，new出KafkaTable对象返回 override def getTable(options: CaseInsensitiveStringMap): KafkaTable = { // 3. includeHeaders：是否包含Kafka 消息header信息 val includeHeaders = options.getBoolean(INCLUDE_HEADERS, false) new KafkaTable(includeHeaders) }

class KafkaTable(includeHeaders: Boolean) extends Table with SupportsRead with SupportsWrite { //1. 结构化数据可以当成一张表，这里就定义了这个表有哪些字段 /** StructField("key", BinaryType), 1.1 字段key StructField("value", BinaryType), 1.2 字段value StructField("topic", StringType), StructField("partition", IntegerType), StructField("offset", LongType), StructField("timestamp", TimestampType), StructField("timestampType", IntegerType), StructField("headers", headersType) 可选 */ override def schema(): StructType = KafkaRecordToRowConverter.kafkaSchema(includeHeaders) //2.该方法返回表示该数据源支持哪些能力 // 对Kafka数据源，一般使用MICRO_BATCH_READ 微批读，STREAMING_WRITE 写能力 // 其他能力暂时可以忽略 override def capabilities(): ju.Set[TableCapability] = { Set(BATCH_READ, BATCH_WRITE, MICRO_BATCH_READ, CONTINUOUS_READ, STREAMING_WRITE, ACCEPT_ANY_SCHEMA).asJava } //3. new 出KafkaScan对象，返回，下文会继续说 override def newScanBuilder(options: CaseInsensitiveStringMap): ScanBuilder = () => new KafkaScan(options) //4. new 出WriteBuilder对象返回，根据capabilities()方法中的BATCH_WRITE，STREAMING_WRITE， // 这边对应有这两种能力 对应的处理对象，buildForBatch，buildForStreaming override def newWriteBuilder(info: LogicalWriteInfo): WriteBuilder = { new WriteBuilder with SupportsTruncate with SupportsStreamingUpdateAsAppend { override def buildForBatch(): BatchWrite = { new KafkaBatchWrite(topic, producerParams, inputSchema) } override def buildForStreaming(): StreamingWrite = { new KafkaStreamingWrite(topic, producerParams, inputSchema) } } } }

class KafkaScan(options: CaseInsensitiveStringMap) extends Scan { override def toBatch(): Batch = { //1.省略这部分功能和代码，批处理 new KafkaBatch( strategy(caseInsensitiveOptions), caseInsensitiveOptions, specifiedKafkaParams, failOnDataLoss(caseInsensitiveOptions), startingRelationOffsets, endingRelationOffsets, includeHeaders) } //2. 和kafka集成后常用的 微批处理 override def toMicroBatchStream(checkpointLocation: String): MicroBatchStream = { val caseInsensitiveOptions = CaseInsensitiveMap(options.asScala.toMap) // 3.每个流计算任务，生成唯一的groupId //这也是为后面管理Kafka offset和partition分配铺垫，后面会详细说 val uniqueGroupId = streamingUniqueGroupId(caseInsensitiveOptions, checkpointLocation) //4. 解析出用户指定的kafka参数，比如kafka broker的鉴权账号密码等 // 可以参考官方文档，options中以kafka. 开头的参数 val specifiedKafkaParams = convertToSpecifiedParams(caseInsensitiveOptions) //5. 根据用户的设置，选择开始读取的位点， //从earliest开始读 或者从指定的offset/timestamp开始读取 val startingStreamOffsets = KafkaSourceProvider.getKafkaOffsetRangeLimit( caseInsensitiveOptions, STARTING_OFFSETS_BY_TIMESTAMP_OPTION_KEY, STARTING_OFFSETS_OPTION_KEY, LatestOffsetRangeLimit) //4.创建一个KafkaOffsetReader对象，其实是对Kafka Consumer/ Kafka AdminClient的封装，主要用于在Driver进程中读取 Offset val kafkaOffsetReader = KafkaOffsetReader.build( strategy(caseInsensitiveOptions), kafkaParamsForDriver(specifiedKafkaParams), caseInsensitiveOptions, driverGroupIdPrefix = s"$uniqueGroupId-driver") //5. 跟前面的差不多，这里构造出一个KafkaMicroBatchStream对象， // 核心的逻辑都在这个类里面了 new KafkaMicroBatchStream( kafkaOffsetReader, kafkaParamsForExecutors(specifiedKafkaParams, uniqueGroupId), options, checkpointLocation, startingStreamOffsets, failOnDataLoss(caseInsensitiveOptions)) } override def toContinuousStream(checkpointLocation: String): ContinuousStream = { //省略这部分功能和代码，连续处理 new KafkaContinuousStream( kafkaOffsetReader, kafkaParamsForExecutors(specifiedKafkaParams, uniqueGroupId), options, checkpointLocation, startingStreamOffsets, failOnDataLoss(caseInsensitiveOptions)) } }

/** * A [[MicroBatchStream]] that reads data from Kafka. * * The [[KafkaSourceOffset]] is the custom [[Offset]] defined for this source that contains * a map of TopicPartition -> offset. Note that this offset is 1 + (available offset). For * example if the last record in a Kafka topic "t", partition 2 is offset 5, then * KafkaSourceOffset will contain TopicPartition("t", 2) -> 6. This is done keep it consistent * with the semantics of `KafkaConsumer.position()`. KafkaSourceOffset这个对象是 Map<TopicPartition, Long>这样一个map，外面包了一层，这个对象可以json序列化和反序列化。 记录了一个Topic下所有partition的offset信息。 * Zero data lost is not guaranteed when topics are deleted. If zero data lost is critical, the user * must make sure all messages in a topic have been processed when deleting a topic. 为了保障数据不丢失，请消费完数据后再删除topic * * There is a known issue caused by KAFKA-1894: the query using Kafka maybe cannot be stopped. * To avoid this issue, you should make sure stopping the query before stopping the Kafka brokers * and not use wrong broker addresses. 这个Jira kafka在 2.0.0以上的版本中已经修复，这里可以忽略。 综上，这个注释信息信息量太少了，还是直接看代码 */ private[kafka010] class KafkaMicroBatchStream( private[kafka010] val kafkaOffsetReader: KafkaOffsetReader, executorKafkaParams: ju.Map[String, Object], options: CaseInsensitiveStringMap, metadataPath: String, startingOffsets: KafkaOffsetRangeLimit, failOnDataLoss: Boolean) extends SupportsAdmissionControl with MicroBatchStream with Logging { //0.初始化参数，得到 Kafka Consumer poll的超时时间，默认120s private[kafka010] val pollTimeoutMs = options.getLong( KafkaSourceProvider.CONSUMER_POLL_TIMEOUT, SparkEnv.get.conf.get(NETWORK_TIMEOUT) * 1000L) //1.当checkpoint不存在时，会走到这个方法，也就是这个Job第一次启动 // 初始化offset信息，从指定的offset开始读取数据，还是从earliest offset开始读取 // 看用户输入的参数。 // 1.当checkpoint 已经存在，说明Job重启了，应该从上一次的计算状态恢复 // Spark会自动从 checkpoint中读取未提交的offset,保障数据不丢, //deserializeOffset方法 反序列化成KafkaSourceOffset对象，继续处理 override def initialOffset(): Offset = { val metadataLog = new KafkaSourceInitialOffsetWriter(SparkSession.getActiveSession.get, metadataPath) var partitionToOffset: Map[TopicPartition, Long] = metadataLog.get(0).getOrElse { val offsets = startingOffsets match { case EarliestOffsetRangeLimit => KafkaSourceOffset(kafkaOffsetReader.fetchEarliestOffsets()) case LatestOffsetRangeLimit => KafkaSourceOffset(kafkaOffsetReader.fetchLatestOffsets(None)) case SpecificOffsetRangeLimit(p) => kafkaOffsetReader.fetchSpecificOffsets(p, reportDataLoss) case SpecificTimestampRangeLimit(p) => kafkaOffsetReader.fetchSpecificTimestampBasedOffsets(p, failsOnNoMatchingOffset = true) } metadataLog.add(0, offsets) logInfo(s"Initial offsets: $offsets") offsets }.partitionToOffsets KafkaSourceOffset(partitionToOffset) } // 用户是否要限制每一批数据的行数 override def getDefaultReadLimit: ReadLimit = { val maxOffsetsPerTrigger = Option(options.get( KafkaSourceProvider.MAX_OFFSET_PER_TRIGGER)).map(_.toLong) maxOffsetsPerTrigger.map(ReadLimit.maxRows).getOrElse(super.getDefaultReadLimit) } //2.kafkaOffsetReader.fetchLatestOffsets //获取这个Topic下 所有partition的 latest offset //具体步骤： kafkaconsumer.poll(0) --> kafkaconsumer.assignment获取所有分区 // 每个分区调一次kafkaconsumer.seekToEnd(partitions) 拿到最新offset，并校验。 // 如果有readlimit，则进行裁剪。 override def latestOffset(start: Offset, readLimit: ReadLimit): Offset = { val startPartitionOffsets = start.asInstanceOf[KafkaSourceOffset].partitionToOffsets val latestPartitionOffsets = kafkaOffsetReader.fetchLatestOffsets(Some(startPartitionOffsets)) endPartitionOffsets = KafkaSourceOffset(readLimit match { case rows: ReadMaxRows => rateLimit(rows.maxRows(), startPartitionOffsets, latestPartitionOffsets) case _: ReadAllAvailable => latestPartitionOffsets }) endPartitionOffsets } //3.startPartitionOffsets，endPartitionOffsets都有了 //这里开始计算 每个partition上的 offsetRange //比如 TopicA-partition1 offsetRange 1000~3000 override def planInputPartitions(start: Offset, end: Offset): Array[InputPartition] = { val startPartitionOffsets = start.asInstanceOf[KafkaSourceOffset].partitionToOffsets val endPartitionOffsets = end.asInstanceOf[KafkaSourceOffset].partitionToOffsets //计算过程中如果发现partition增加，会读取new Partition的earliest offset //并根据“numPartitions”，“minPartitions” 参数计算生成多少个Spark tasks（Spark计算任务） //默认一个Kafka Partition mapping 一个Spark task val offsetRanges = kafkaOffsetReader.getOffsetRangesFromResolvedOffsets( startPartitionOffsets, endPartitionOffsets, reportDataLoss ) // 构造KafkaBatchInputPartition对象 // 一个KafkaBatchInputPartition对象会mapping一个Spark task（Spark计算任务） offsetRanges.map { range => KafkaBatchInputPartition(range, executorKafkaParams, pollTimeoutMs, failOnDataLoss, includeHeaders) }.toArray } //4.每个KafkaBatchInputPartition对象会mapping一个Spark task（Spark计算任务） // 这边就是构造 对每个partition读取数据用的对象 override def createReaderFactory(): PartitionReaderFactory = { KafkaBatchReaderFactory } // 1.工具方法，将json反序列化成 KafkaSourceOffset对象 // 比如Job重启时，Spark会自动从 checkpoint中读取未提交的offset // 通过此方法 反序列化成对象，继续处理 // 保障数据不丢 override def deserializeOffset(json: String): Offset = { KafkaSourceOffset(JsonUtils.partitionOffsets(json)) } //一批数据处理完成后，会走到这里，可以自定义操作，kafka这边啥也没干 override def commit(end: Offset): Unit = {} override def stop(): Unit = { kafkaOffsetReader.close() } }

object KafkaBatchReaderFactory extends PartitionReaderFactory { override def createReader(partition: InputPartition): PartitionReader[InternalRow] = { val p = partition.asInstanceOf[KafkaBatchInputPartition] KafkaBatchPartitionReader(p.offsetRange, p.executorKafkaParams, p.pollTimeoutMs, p.failOnDataLoss, p.includeHeaders) } }

private case class KafkaBatchPartitionReader( offsetRange: KafkaOffsetRange, executorKafkaParams: ju.Map[String, Object], pollTimeoutMs: Long, failOnDataLoss: Boolean, includeHeaders: Boolean) extends PartitionReader[InternalRow] with Logging { // 1.获取KafkaDataConsumer，内部对KafkaConsumer进行了cache private val consumer = KafkaDataConsumer.acquire(offsetRange.topicPartition, executorKafkaParams) //2.计算当前offsetRange是否在有startOffset< -1等奇怪的情况 private val rangeToRead = resolveRange(offsetRange) //3.设置一个将Kafka ConsumerRecord[Array[Byte], Array[Byte]] //转成Spark InternalRow的转换器 private val unsafeRowProjector = new KafkaRecordToRowConverter() .toUnsafeRowProjector(includeHeaders) //4. 从第一个offset开始读取 private var nextOffset = rangeToRead.fromOffset //5.迭代器模型 private var nextRow: UnsafeRow = _ //6.迭代器模型 override def next(): Boolean = { //6.1 判断offset是否在范围内 if (nextOffset < rangeToRead.untilOffset) { //6.2 poll一条数据 val record = consumer.get(nextOffset, rangeToRead.untilOffset, pollTimeoutMs, failOnDataLoss) if (record != null) { //6.3 将kafka ConsumerRecord转成 InternalRow，即将被迭代 nextRow = unsafeRowProjector(record) //6.3 offset ++ nextOffset = record.offset + 1 true } else { false } } else { false } } //7. 如果next() 方法返回true，执行器线程会调用这个方法拿InternalRow override def get(): UnsafeRow = { assert(nextRow != null) nextRow } //8.一个微批的数据读取完成后，释放consumer对象 override def close(): Unit = { consumer.release() } }

val record = consumer.get(nextOffset, rangeToRead.untilOffset, pollTimeoutMs, failOnDataLoss)

 def get( offset: Long, // 开始位点 untilOffset: Long, // 结束位点 pollTimeoutMs: Long, // poll 超时时间 failOnDataLoss: Boolean):// 当offset在Broker上已经过期，停止任务，避免数据丢失 ConsumerRecord[Array[Byte], Array[Byte]] = runUninterruptiblyIfPossible { //从InternalKafkaConsumerPool获取一个InternalKafkaConsumer，如果pool中没有则创建 //创建过程中会调用KafkaConsumer.assgin(TopicPartion) //基本类似Map.computeIfAbsent //缓存的key 为本次任务的id+ TopicPartition val consumer: InternalKafkaConsumer = getOrRetrieveConsumer() //与上面类似，获取kafka数据缓存区，因为每次poll到的数据量可能大于 //需要的数据量，所以poll到的数据会先缓存起来 val fetchedData: FetchedData = getOrRetrieveFetchedData(offset) var isFetchComplete = false while (toFetchOffset != UNKNOWN_OFFSET && !isFetchComplete) { try { //fetchRecord方法见下文 fetchedRecord = fetchRecord(consumer, fetchedData, toFetchOffset, untilOffset, pollTimeoutMs, failOnDataLoss) //获取到数据，结束 if (fetchedRecord.record != null) { isFetchComplete = true } else { //如果指定的 fromOffset 在Kafka Broker上已经过期 //找找缓存中有没有 `[fromOffset, untilOffset)` 这个范围内的数据。 //找到的话会 掉过一部分数据。 toFetchOffset = fetchedRecord.nextOffsetToFetch if (toFetchOffset >= untilOffset) { fetchedData.reset() toFetchOffset = UNKNOWN_OFFSET } else { logDebug(s"Skipped offsets [$offset, $toFetchOffset]") } } } catch { case e: OffsetOutOfRangeException => //遇到异常，清理缓存的KafkaConsumer 和 数据缓存 releaseConsumer() fetchedData.reset() //根据failOnDataLoss参数的设置 //true:抛出异常到外层，结束Job，防止数据丢失 （推荐） //false:跳过这条数据，继续Job，部分数据丢失 reportDataLoss(topicPartition, groupId, failOnDataLoss, s"Cannot fetch offset $toFetchOffset", e) toFetchOffset = getEarliestAvailableOffsetBetween(consumer, toFetchOffset, untilOffset) } } if (isFetchComplete) { fetchedRecord.record } else { fetchedData.reset() null } }

/** * Get the fetched record for the given offset if available. * * @throws OffsetOutOfRangeException if `offset` is out of range * @throws TimeoutException if cannot fetch the record in `pollTimeoutMs` milliseconds. */ private def fetchRecord( consumer: InternalKafkaConsumer, fetchedData: FetchedData, offset: Long, untilOffset: Long, pollTimeoutMs: Long, failOnDataLoss: Boolean): FetchedRecord = { //如果fromOffset在缓存中不存在 if (offset != fetchedData.nextOffsetInFetchedData) { //进行KafkaConsumer.seek && KafkaConsumer.poll 见下文 fetch(consumer, fetchedData, offset, pollTimeoutMs) } //poll到数据后包装并返回 val record = fetchedData.next() fetchedRecord.withRecord(record, fetchedData.nextOffsetInFetchedData) }

def fetch(offset: Long, pollTimeoutMs: Long): (ju.List[ConsumerRecord[Array[Byte], Array[Byte]]], Long, AvailableOffsetRange) = { //1.先 seek到指定位置 consumer.seek(topicPartition, offset) //2.拉取数据 val p: ConsumerRecords[Array[Byte], Array[Byte]] = consumer.poll(Duration.ofMillis(pollTimeoutMs)) // 3.过滤出指定partition的数据 val r = p.records(topicPartition) //4. 获取当前consumer的最新offset val offsetAfterPoll = consumer.position(topicPartition) logDebug(s"Offset changed from $offset to $offsetAfterPoll after polling") //5. 获取partition earliest和latest Offset，判断有没有超出。 val range = getAvailableOffsetRange() val fetchedData = (r, offsetAfterPoll, range) fetchedData }

并不是，只有一个微批处理的开始，数据源会去检测Topic下每个partition offsets是否有更新。 如果Trigger间隔时间很长，那么这段时间内Topic中新增的数据，Spark是无感知的。

对于Source来说： 当一个微批处理开始的时候，Driver进程将offset写入checkpoint中， 当一个微批处理完成时（Sink成功），Driver进程将commit信息写入checkpoint中， 当Job失败重启的时候，可以从checkpoint中恢复Job到上一个commit的状态，保障数据不重复不丢失。

Spark每一个微批处理开始前都是先获取Topic下所有Partition的最新Offset（LEO），和上次已经处理完成的Offset对比 计算有哪些partition上有offset更新，以及要拉取的offset范围。 在Driver进程中，这些partition一对一映射成为Spark Task（Spark计算任务）， 组成TaskPool，由Executor执行Task，至于Task的调度由Spark内部实现。 所以，默认参数情况下，如果Topic下Partition数量远大于Executor数量，会导致数据拉取执行缓慢 可以增加Executor或者通过numPartitions参数调整

Spark每一个微批处理开始前都是先获取Topic下所有Partition的最新Offset（LEO） 根据readlimit参数，计算每个partition的 untilOffset写入checkpoint 处理过程中，用Kafka Consumer的seek方法，指定offset消费，只消费[fromOffset,untilOffset) 范围内的数据，左闭右开。 当一批数据处理完成后写入commit信息

Data Source interfaces in Spark 3.0.0 主要有以下的接口 - TableProvider - Table - ScanBuilder - Scan - MicroBatchStream - InputPartition - PartitionReaderFactory - PartitionReader 实现以上接口即可。 官方sample Java版 https://github.com/apache/spark/blob/72615bc551adaa238d15a8b43a8f99aaf741c30f/sql/core/src/test/java/test/org/apache/spark/sql/connector/JavaPartitionAwareDataSource.java

详细视频：- https://www.youtube.com/watch?v=9-eomYXVnvY&ab_channel=Databricks 主要的改进是 并发读取数据、过滤器下推(filters push down)、加速聚合操作，增加Spark Data Encoding、数据统计和分片、支持Structured Streaming等
