Energy Load Forecast with Visualization in Interactive Tool

In this notebook, we will show how to use NeuralProphet to forecast energy load and visualize the results in an interactive tool. The forecast is based on the RE-Europe data set, which models the continental European electricity system, including demand and renewable energy inflows for the period 2012-2014. The total data set comprises 1494 buses, which we will reduce to 5 buses for the purpose of this example.

import pandas as pd import numpy as np from neuralprophet import NeuralProphet, set_log_level import plotly.graph_objects as go import plotly.express as px from plotly.subplots import make_subplots import ipywidgets as widgets from ipywidgets import interact_manual # Set plotting backend to plotly for interactive plots and plotly-static for static plots plotting_backend = "plotly-static"

The dataset includes for every bus and every hour of the year the following information: * load (MW) * actual solar production (MW) * forecasted solar production (MW)

The forecasts are at hour 00 of every day for the next 24 hours.

# load data df = pd.read_csv( "https://raw.githubusercontent.com/ourownstory/neuralprophet-data/main/datasets/multivariate/ER_Europe_subset_10nodes.csv" ) df["ID"] = df["ID"].astype(str) IDs = df["ID"].unique() df["ds"] = pd.to_datetime(df["ds"]) # use one year for faster training df = df[df["ds"] > "2014-01-01"] df.head()

	ds	ID	y	solar	solar_fcs
17545	2014-01-01 01:00:00	1	72.3142	0.0	0.0
17546	2014-01-01 02:00:00	1	67.5617	0.0	0.0
17547	2014-01-01 03:00:00	1	63.0677	0.0	0.0
17548	2014-01-01 04:00:00	1	59.9401	0.0	0.0
17549	2014-01-01 05:00:00	1	58.9296	0.0	0.0

# plot first month of data fig = px.line(df[df["ds"] < "2014-02-01"], x="ds", y="y", color="ID") fig.update_layout( xaxis_title="Date", yaxis_title="Energy consumption", legend_title="ID", height=600, width=1000, ) if plotting_backend == "plotly-static": fig.show("svg")

1. Data Preparation

To better capture different seasons of the year and days of the week, we add conditional seasonaility. For every season of the year (summer, winter, fall and spring) and weekdays/weekend a separate seasonality is modelled.

# Conditional Seasonality: 4 Seasons for yearly and weekly seasonality df["summer"] = 0 df.loc[df["ds"].dt.month.isin([6, 7, 8]), "summer"] = 1 df["winter"] = 0 df.loc[df["ds"].dt.month.isin([12, 1, 2]), "winter"] = 1 df["fall"] = 0 df.loc[df["ds"].dt.month.isin([9, 10, 11]), "fall"] = 1 df["spring"] = 0 df.loc[df["ds"].dt.month.isin([3, 4, 5]), "spring"] = 1 # Conditional Seasonality: 4 Seasons, Weekday/Weekend distinction for each season, for daily seasonality df["summer_weekday"] = 0 df.loc[(df["ds"].dt.month.isin([6, 7, 8])) & (df["ds"].dt.dayofweek.isin([0, 1, 2, 3, 4])), "summer_weekday"] = 1 df["summer_weekend"] = 0 df.loc[(df["ds"].dt.month.isin([6, 7, 8])) & (df["ds"].dt.dayofweek.isin([5, 6])), "summer_weekend"] = 1 df["winter_weekday"] = 0 df.loc[(df["ds"].dt.month.isin([12, 1, 2])) & (df["ds"].dt.dayofweek.isin([0, 1, 2, 3, 4])), "winter_weekday"] = 1 df["winter_weekend"] = 0 df.loc[(df["ds"].dt.month.isin([12, 1, 2])) & (df["ds"].dt.dayofweek.isin([5, 6])), "winter_weekend"] = 1 df["spring_weekday"] = 0 df.loc[(df["ds"].dt.month.isin([3, 4, 5])) & (df["ds"].dt.dayofweek.isin([0, 1, 2, 3, 4])), "spring_weekday"] = 1 df["spring_weekend"] = 0 df.loc[(df["ds"].dt.month.isin([3, 4, 5])) & (df["ds"].dt.dayofweek.isin([5, 6])), "spring_weekend"] = 1 df["fall_weekday"] = 0 df.loc[(df["ds"].dt.month.isin([9, 10, 11])) & (df["ds"].dt.dayofweek.isin([0, 1, 2, 3, 4])), "fall_weekday"] = 1 df["fall_weekend"] = 0 df.loc[(df["ds"].dt.month.isin([9, 10, 11])) & (df["ds"].dt.dayofweek.isin([5, 6])), "fall_weekend"] = 1 df.head()

	ds	ID	y	solar	solar_fcs	summer	winter	fall	spring	summer_weekday	summer_weekend	winter_weekday	winter_weekend	spring_weekday	spring_weekend	fall_weekday	fall_weekend
17545	2014-01-01 01:00:00	1	72.3142	0.0	0.0	0	1	0	0	0	0	1	0	0	0	0	0
17546	2014-01-01 02:00:00	1	67.5617	0.0	0.0	0	1	0	0	0	0	1	0	0	0	0	0
17547	2014-01-01 03:00:00	1	63.0677	0.0	0.0	0	1	0	0	0	0	1	0	0	0	0	0
17548	2014-01-01 04:00:00	1	59.9401	0.0	0.0	0	1	0	0	0	0	1	0	0	0	0	0
17549	2014-01-01 05:00:00	1	58.9296	0.0	0.0	0	1	0	0	0	0	1	0	0	0	0	0

2. Model definition

The best parameters for the model can be obtained with hyperparameter tuning. By setting the quantiles, a prediction interval is modelled instead of a point forecast.

# Model and prediction quantiles = [0.015, 0.985] params = { "n_lags": 7 * 24, "n_forecasts": 24, "n_changepoints": 20, "learning_rate": 0.01, "ar_layers": [32, 16, 16, 32], "yearly_seasonality": 10, "weekly_seasonality": False, "daily_seasonality": False, "epochs": 40, "batch_size": 1024, "quantiles": quantiles, } m = NeuralProphet(**params) m.set_plotting_backend(plotting_backend) set_log_level("ERROR")

2.1 Lagged and future regressors

With additional information, our model can get better. We use the last 10 days of the actual solar production as lagged regressor and the solar forecast as the future regressor.

m.add_lagged_regressor(names="solar", n_lags=10 * 24) m.add_future_regressor(name="solar_fcs")

 <neuralprophet.forecaster.NeuralProphet at 0x12cc57b20>

2.2 Conditional seasonalities

m.add_seasonality(name="summer_weekly", period=7, fourier_order=14, condition_name="summer") m.add_seasonality(name="winter_weekly", period=7, fourier_order=14, condition_name="winter") m.add_seasonality(name="spring_weekly", period=7, fourier_order=14, condition_name="spring") m.add_seasonality(name="fall_weekly", period=7, fourier_order=14, condition_name="fall") m.add_seasonality(name="summer_weekday", period=1, fourier_order=6, condition_name="summer_weekday") m.add_seasonality(name="winter_weekday", period=1, fourier_order=6, condition_name="winter_weekday") m.add_seasonality(name="spring_weekday", period=1, fourier_order=6, condition_name="spring_weekday") m.add_seasonality(name="fall_weekday", period=1, fourier_order=6, condition_name="fall_weekday") m.add_seasonality(name="summer_weekend", period=1, fourier_order=6, condition_name="summer_weekend") m.add_seasonality(name="winter_weekend", period=1, fourier_order=6, condition_name="winter_weekend") m.add_seasonality(name="spring_weekend", period=1, fourier_order=6, condition_name="spring_weekend") m.add_seasonality(name="fall_weekend", period=1, fourier_order=6, condition_name="fall_weekend")

 <neuralprophet.forecaster.NeuralProphet at 0x12cc57b20>

3. Model training

To test our model later, data is split into training and test data. The test data is the last 5% of the data. The model is trained on the training data.

# Split Train and Test Data df_train, df_test = m.split_df(df, valid_p=0.05, local_split=True) print(f"Train shape: {df_train.shape}") print(f"Test shape: {df_test.shape}")

 Train shape: (41545, 17) Test shape: (3090, 17)

# Fit model metrics_fit = m.fit(df_train, freq="H", metrics=True)

# Predict forecast = m.predict(df)

# extract season columns and convert to numeric season_cols = [col for col in forecast.columns if "season" in col or "trend" in col] forecast[season_cols] = forecast[season_cols].apply(pd.to_numeric)

4. Visualization

4.1 Model plots

NeuralProphet includes plot functions to explore the forecasted data. For an overview over the plot functions see the Visualizing tutorial.

m.highlight_nth_step_ahead_of_each_forecast(1).plot(forecast.iloc[-10 * 24 :])

m.plot_parameters(components=["trend", "trend_rate_change", "lagged_regressors"])

4.2 Interactive tool

Let’s explore the data more interactively. By choosing a date, the forecast for the next 24 hours is shown, which represents industry standards.

def get_day_ahead_format(date, ID, column_name): values = pd.DataFrame(columns=["ds", column_name]) forecast_ID = forecast[forecast["ID"] == ID] for i in range(0, 24): if "%" in column_name: step_name = f"yhat{i+1} {column_name}" # eg yhat10 1.5% else: step_name = f"{column_name}{i+1}" ds = date + pd.Timedelta(hours=i + 1) # throw an error if the date is not in the forecast if ds not in forecast_ID["ds"].values: raise ValueError( f'The date {ds} is not in the forecast. Please choose a date between {forecast_ID["ds"].min()} and {forecast_ID["ds"].max()}' ) step_value = forecast_ID[forecast_ID["ds"] == ds][step_name].values[0] values = pd.concat([values, pd.DataFrame({"ds": ds, column_name: step_value}, index=[0])], ignore_index=True) return values

@interact_manual # with this line of code the forecast becomes interactive by letting you choose the ID and date def show_forecast_uncertainty(ID=IDs, date=widgets.DatePicker()): start = pd.to_datetime(date) end = start + pd.DateOffset(days=1) # get forecast np_yhats = get_day_ahead_format(start, ID, "yhat") np_yhats_lower = get_day_ahead_format(start, ID, "1.5%") np_yhats_upper = get_day_ahead_format(start, ID, "98.5%") np_ar = get_day_ahead_format(start, ID, "ar") # get actual, temp and temp forecast forecast_window = forecast[forecast["ID"] == ID] forecast_window = forecast_window[(forecast_window["ds"] >= start) & (forecast_window["ds"] < end)] df_window = df[df["ID"] == ID] df_window = df_window[(df_window["ds"] >= start) & (df_window["ds"] < end)] # get components seasonalities_to_plot = [] for season in season_cols: if np.abs(forecast_window[season].sum()) > 0: seasonalities_to_plot.append(season) fig = make_subplots( rows=3, cols=1, shared_xaxes=True, subplot_titles=("Actuals and Forecast", "Solar production", "Forecast Components"), ) # plot actuals fig.add_trace( go.Scatter( x=forecast_window["ds"], y=forecast_window["y"], name="Actuals", mode="markers", marker=dict(symbol="x") ), row=1, col=1, ) # plot forecast and uncertainty fig.add_trace( go.Scatter( x=np_yhats_lower["ds"], y=np_yhats_lower["1.5%"], fill=None, mode="lines", line_color="#A6B168", name="1.5% quantile", ), row=1, col=1, ) fig.add_trace( go.Scatter( x=np_yhats_upper["ds"], y=np_yhats_upper["98.5%"], fill="tonexty", mode="lines", line_color="#A6B168", name="98.5% quantile", ), row=1, col=1, ) fig.add_trace(go.Scatter(x=np_yhats["ds"], y=np_yhats["yhat"], name="Forecast", line_color="#7A863B"), row=1, col=1) # plot solar fig.add_trace( go.Scatter(x=df_window["ds"], y=df_window["solar"], mode="lines", name="Solar actual production"), row=2, col=1 ) fig.add_trace( go.Scatter(x=df_window["ds"], y=df_window["solar_fcs"], mode="lines", name="Solar forecast production"), row=2, col=1, ) # plot different seasons of seasons_to_plot for season in seasonalities_to_plot: fig.add_trace(go.Scatter(x=forecast_window["ds"], y=forecast_window[season], name=season), row=3, col=1) fig.add_trace(go.Scatter(x=np_ar["ds"], y=np_ar["ar"], name="Autoregression"), row=3, col=1) fig.update_layout( title=f"Forecast for ID {ID} on {date}", yaxis=dict(title="Load (MW)"), width=1200, height=800, ) if plotting_backend == "plotly-static": fig.show("svg") else: fig.show()
