6. Choropleth maps

This notebook is optimized to run in Google Colab.

In [2]:

import pandas as pd import plotly.graph_objects as go import numpy as np from urllib.request import urlopen import json from fast_dash import fastdash, Graph

import pandas as pd import plotly.graph_objects as go import numpy as np from urllib.request import urlopen import json from fast_dash import fastdash, Graph

In [3]:

# Counties sample data with urlopen('https://raw.githubusercontent.com/plotly/datasets/master/geojson-counties-fips.json') as response: counties = json.load(response) counties_df = pd.read_csv("https://raw.githubusercontent.com/plotly/datasets/master/fips-unemp-16.csv", dtype={"fips": str}) # US Ag exports sample data us_ag_exports_df = pd.read_csv('https://raw.githubusercontent.com/plotly/datasets/master/2011_us_ag_exports.csv') for col in us_ag_exports_df.columns: us_ag_exports_df[col] = us_ag_exports_df[col].astype(str) us_ag_exports_df['text'] = us_ag_exports_df['state'] + '<br>' + \ 'Beef ' + us_ag_exports_df['beef'] + ' Dairy ' + us_ag_exports_df['dairy'] + '<br>' + \ 'Fruits ' + us_ag_exports_df['total fruits'] + ' Veggies ' + us_ag_exports_df['total veggies'] + '<br>' + \ 'Wheat ' + us_ag_exports_df['wheat'] + ' Corn ' + us_ag_exports_df['corn']

# Counties sample data with urlopen('https://raw.githubusercontent.com/plotly/datasets/master/geojson-counties-fips.json') as response: counties = json.load(response) counties_df = pd.read_csv("https://raw.githubusercontent.com/plotly/datasets/master/fips-unemp-16.csv", dtype={"fips": str}) # US Ag exports sample data us_ag_exports_df = pd.read_csv('https://raw.githubusercontent.com/plotly/datasets/master/2011_us_ag_exports.csv') for col in us_ag_exports_df.columns: us_ag_exports_df[col] = us_ag_exports_df[col].astype(str) us_ag_exports_df['text'] = us_ag_exports_df['state'] + '
' + \ 'Beef ' + us_ag_exports_df['beef'] + ' Dairy ' + us_ag_exports_df['dairy'] + '
' + \ 'Fruits ' + us_ag_exports_df['total fruits'] + ' Veggies ' + us_ag_exports_df['total veggies'] + '
' + \ 'Wheat ' + us_ag_exports_df['wheat'] + ' Corn ' + us_ag_exports_df['corn']

In [4]:

@fastdash(theme="flatly") def visualize_states_and_counties(a: int) -> (Graph, Graph):  """  Fast Dash allows quick and easy visualization of various geographies.\  This application plots states and counties using two differnent basemaps.\  Reference: https://plotly.com/python/mapbox-county-choropleth/.  """ # Plotly-native graph map fig = go.Figure(data=go.Choropleth( locations=us_ag_exports_df['code'], z=us_ag_exports_df['total exports'].astype(float), locationmode='USA-states', colorscale='Reds', autocolorscale=False, text=us_ag_exports_df['text'], # hover text marker_line_color='white', # line markers between states colorbar_title="Millions USD" )) fig.update_layout( title_text='2011 US Agriculture Exports by State<br>(Hover for breakdown)', geo = dict( scope='usa', projection=go.layout.geo.Projection(type = 'albers usa'), showlakes=True, # lakes lakecolor='rgb(255, 255, 255)'), ) plotly_express = fig # Mapbox graph map fig = go.Figure(go.Choroplethmapbox(geojson=counties, locations=counties_df.fips, z=counties_df.unemp, colorscale="Viridis", zmin=0, zmax=12, marker_line_width=0)) fig.update_layout(mapbox_style="light", mapbox_accesstoken="...", mapbox_zoom=3, mapbox_center = {"lat": 37.0902, "lon": -95.7129}) fig.update_layout(margin={"r":0,"t":0,"l":0,"b":0}) mapbox = fig return plotly_express, mapbox

@fastdash(theme="flatly") def visualize_states_and_counties(a: int) -> (Graph, Graph): """ Fast Dash allows quick and easy visualization of various geographies.\ This application plots states and counties using two differnent basemaps.\ Reference: https://plotly.com/python/mapbox-county-choropleth/. """ # Plotly-native graph map fig = go.Figure(data=go.Choropleth( locations=us_ag_exports_df['code'], z=us_ag_exports_df['total exports'].astype(float), locationmode='USA-states', colorscale='Reds', autocolorscale=False, text=us_ag_exports_df['text'], # hover text marker_line_color='white', # line markers between states colorbar_title="Millions USD" )) fig.update_layout( title_text='2011 US Agriculture Exports by State
(Hover for breakdown)', geo = dict( scope='usa', projection=go.layout.geo.Projection(type = 'albers usa'), showlakes=True, # lakes lakecolor='rgb(255, 255, 255)'), ) plotly_express = fig # Mapbox graph map fig = go.Figure(go.Choroplethmapbox(geojson=counties, locations=counties_df.fips, z=counties_df.unemp, colorscale="Viridis", zmin=0, zmax=12, marker_line_width=0)) fig.update_layout(mapbox_style="light", mapbox_accesstoken="...", mapbox_zoom=3, mapbox_center = {"lat": 37.0902, "lon": -95.7129}) fig.update_layout(margin={"r":0,"t":0,"l":0,"b":0}) mapbox = fig return plotly_express, mapbox

WARNING:root:Parsing function docstring is still an experimental feature. To reduce uncertainty, consider setting `about` to `False`.
